Oil Sight Glass & Level Monitor - 3" Dual Port


Des-Case Oil Sight Glass & Level Monitor - 3 inch Dual Port

0 ratings | Submit a rating
$258.90  Cart is in US Dollar
Oil Sight Glass Level Monitor

Inspect, analyze, and remove contaminants as well as manage your oil levels.

Brand: Des-Case
Part Number:
DC-OSGL3DP




OVERVIEW

The Oil Sight Glass Level Monitor (OSGL) allows you to view oil color, clarity and accumulation of water or other contaminants while monitoring the level of the oil in the reservoir. It is available in multiple lengths ranging from 3" to 24" to correspond to the distance from the oil reservoir access port and the maximum height the oil will reach. A dual port version is available with a second 3/8" NPT port opposite the installation nipple to allow the installation of a sampling tube to draw representative oil samples without pulling outside contaminants.

SPECIFICATIONS

  • Material:
  • Stain-resistant acrylic
  • Brass fittings standard
  • Des-Case ND-2 breather 0.3 micron Absolute (Beta 1000)
  • Recommended Temperature Range:
  • -40F to 200F
  • -40C to 93C
  • Maximum Operating Pressure:
  • 65 psi
  • 4.48 bar
  • Chemical Compatibility:
  • All gear, mineral and synthetic oils
  • Available Options:
  • 3/8" NPT single port or dual ports
  • Length 3"
  • Stainless steel fittings
  • Magnetic drain valve for collecting ferrous material

FEATURES

  • Key Benefits:
  • view of oil clarity and color
  • Monitor oil level
  • Attaches to machine drain ports
  • Detect accumulation of water and contaminants
