D Series Filtercart


Lubrigard D Series Filtercart

0 ratings | Submit a rating
Price: Call for price 1-800-268-2131  Cart is in US Dollar
Simple and Powerful.

D Series FilterCart - Simple and Powerful.

Brand: Lubrigard
Part Number:
LG-HTD5WR45WH1SQ140R1
Availability: Please Contact




OVERVIEW

The Y2K HT-D Series Filter Cart is our signature filter cart and is an excellent choice for "off-line" filtration in a wide variety of settings. Extremely mobile and lightweight, this filter cart has all the power needed for filtering oil viscosities up to 600cSt (ISO VG 680). This filter cart is completely customizable to fit all of your needs.

Typical Applications:

  • Filtering contaminated system
  • Flushing new or repaired systems
  • Pre-filtering new oil
  • Transferring oils
  • Topping off reservoirs
  • Collecting oil samples for analysis
  • Dispensing new oil

SPECIFICATIONS

  • Hand Truck Filter Cart
  • Flat Free Tires
  • Dual 50 Psi Bypass Filter Heads With Color Coded Differential Pressure Indictors
  • Water Removal First Stage P1048WR
  • 4 Micron Beta 2000 Second Stage P1066
  • 7' Suction and Discharge Hose Hydraulic, With ISO B Quick Disconnects (1" and ¾")(I used Black Hydraulic Hose on this one just to be safe)
  • 40' Retractable Electric Cord Reel` 1HP motor TEFC 110VAC
  • 5GPM Heavy Duty Gear Pump
  • Color Blaze Orange
  • NOTE: ITEM MAY NOT BE EXACTLY AS SHOWN

FEATURES

  • Frame: Carbon steel with drip pan
  • Paint: Industrial powder coat; various colors available
  • Motor: 1HP, 115vac, 60Hz or Pneumatic Air
  • Filter Heads: Medium pressure, steel heads
  • Pump: Heavy duty steel gear pump. Available in 1, 2, 5 and 10 GPM
  • Connections: ISO A, ISO B, Flush Face and Camlock options available
  • Hoses: 7ft. Clear PVC, steel reinforced hose or hydraulic hose
  • Power Switch: Sealed on/off power switch
  • Filter Indicators: Slide bar indicator triggers at 50psid when elements need to be changed
  • Pump Relief: Opens at 150psi
  • Weight: Approx 125lbs (will vary depending on options)
