Panel Unit 1HP, 5GPM, SPCL Hooks/Lifting


Lubrigard Panel Unit 1HP, 5GPM, SPCL Hooks/Lifting

1 ratings | Submit a rating
$5,108.75  Cart is in US Dollar
Compact and Portable

D Series FilterCart - Compact and Portable.

Brand: Lubrigard
Part Number:
LG-PUD5WR45SHSQ4P4-LOZ




OVERVIEW

When you need to install a permanent, continuous duty solution for your offline filtration, the PU-D Panel Unit is the perfect solution. Available in a variety of sizes, it will suit any space requirement you may have. These filtration systems have all the power needed for filtering oil viscosities up to 600cSt (ISO VG 680) at 100F within ambient temperature ranges of -15F to 150F. All Y2K products are 100% customizable upon request.

Typical Applications:

  • Filtering contaminated system
  • Collecting oil samples for analysis
  • Dispensing new oil
  • Permanent Installations

SPECIFICATIONS

  • Heavy Duty Panel Unit
  • Dual 50 PSI Bypass Filter Heads W/ Slide Type Color Coded Differential Pressure Indicators
  • Water Removal First Stage P1048WR
  • 4 Micron Beta 2000 Second Stage P1066
  • 1HP Motor TEFC 110VAC
  • 5 GPM Heavy-Duty Cast-Iron Gear Pump W/ 150 PSI Relief Valve
  • 7' Suction and Discharge Hoses With ISO B Quick Disconnects (3/4" & 1/2")
  • Sealed Switch
  • 4' Electric Cord With Three Prong Plug
  • Textured Black Powder Coat: Oil Resistive Grip For Safety
  • (L)Lifting Lugs (At the top of the panel for easy lifting)
  • (O)Oil Sample Ports Up/Down Stream
  • (Z) Hooks x2 (Hooks on both sides of the Panel for hooking on a steel Caged Tote)

FEATURES

  • Frame: Carbon steel with drip tray
  • Paint: Multiple color options available
  • Motor: 1HP, 115vac, 60Hz or Pneumatic
  • Filter Heads: Medium pressure, cast aluminum heads
  • Pump: Heavy duty, cast steel gear pump. Available in 1, 2, 5 and 10 GPM
  • Filter Indicators: Slide bar indicator triggers at 50psid when elements need to be changed
  • Pump Relief: Opens at 150psi
  • Weight: Approx 125lbs (will vary depending on options)
  • Dimensions: Approx 24"L x 12"W x 29"H
