Panel Unit 5GPM 1HP SPCL For Use With Engine Oil TO4+30

Lubrigard Panel Unit 5GPM 1HP SPCL For Use With Engine Oil TO4+30

0 ratings | Submit a rating
Price: Call for price 1-800-268-2131  Cart is in US Dollar
Compact and Portable

Panel Unit, 5GPM, 1HP For Use With Engine Oil TO4+30

Brand: Lubrigard
Part Number:


When you need to install a permanent, continuous duty solution for your offline filtration, the PU-D Panel Unit is the perfect solution. Available in a variety of sizes, it will suit any space requirement you may have. These filtration systems have all the power needed for filtering oil viscosities up to 600cSt (ISO VG 680) at 100F within ambient temperature ranges of -15F to 150F. All Y2K products are 100% customizable upon request.

Typical Applications:

  • Filtering contaminated system
  • Collecting oil samples for analysis
  • Dispensing new oil
  • Permanent Installations


  • Heavy Duty Panel Unit
  • Dual 50 PSI Bypass Filter Heads W/ Slide Type Color Coded Differential Pressure Indicators
  • Water Removal First Stage P1048WR
  • 7 Micron Beta 2000 Second Stage P1065
  • 1HP Motor TEFC 110VAC
  • 5 GPM Heavy-Duty Cast-Iron Gear Pump W/ 150 PSI Relief Valve
  • No Hoses
  • No Cord
  • 24/7 On/Off Timer
  • Z = Shut Off Valves on Inlet/Outlet of Filters
  • Z = Drip Pan Under Elements
  • Powder Coat Yellow
