Lubrigard Panel Unit, 5GPM, Air Operated

When you need to install a permanent, continuous duty solution for your offline filtration, the PU-D Panel Unit is the perfect solution. Available in a variety of sizes, it will suit any space requirement you may have. These filtration systems have all the power needed for filtering oil viscosities up to 600cSt (ISO VG 680) at 100F within ambient temperature ranges of -15F to 150F. All Y2K products are 100% customizable upon request.

Typical Applications:

• Filtering contaminated system
• Collecting oil samples for analysis
• Dispensing new oil
• Permanent Installations

• Panel Unit, Private Label Lubrigard
• Dual 50 PSI Bypass Filter Heads W/ Color Coded Differential Pressure Indicators
• 7 Micron Beta 2000 First Stage P1065
• 4 Micron Beta 2000 Second Stage P1066
• 1.5 HP Air Operated Motor, With Filter, Regulator and Lubricator
• 5 GPM Heavy Duty Cast Iron Gear Pump W/ 150 PSI Relief Valve
• Hydraulic Jumper Hose from Pump to Filter
• Orange Powder Coat
• Manual Bypass
• Push Button Sample Ports Up/ Down Stream
• *No Hoses or Switch
• ***UNIT MAY NOT BE EXACTLY AS SHOWN***

• Frame: Carbon steel with drip tray
• Paint: Multiple color options available
• Motor: 1HP, 115vac, 60Hz or Pneumatic
• Filter Heads: Medium pressure, cast aluminum heads
• Pump: Heavy duty, cast steel gear pump. Available in 1, 2, 5 and 10 GPM
• Filter Indicators: Slide bar indicator triggers at 50psid when elements need to be changed
• Pump Relief: Opens at 150psi
• Weight: Approx 125lbs (will vary depending on options)
• Dimensions: Approx 24"L x 12"W x 29"H
